Select all the equations on which the point (10, 0) lies.

You are hitting a nail with a hammer (mass of hammer =1.8lb) the initial velocity of the hammer is 50 mph (73.33 ft/sec). The ti

Archy [21]

Answer:

The nail exerts a force of 573.88 Pounds on the Hammer in positive j direction.

Explanation:

Since we know that the force is the rate at which the momentum of an object changes.

Mathematically $\overrightarrow{F}=\frac{\Delta \overrightarrow{p}}{\Delta t}$

The momentum of any body is defines as $\overrightarrow{p}=mass\times \overrightarrow{v}$

In the above problem we see that the moumentum of the hammer is reduced to zero in 0.023 seconds thus the force on the hammer is calculated using the above relations as

$\overrightarrow{F}=\frac{m(\overrightarrow{v_{f}}-\overrightarrow{v_{i}})}{\Delta t}$

$\overrightarrow{F}=\frac{m(0-(-73.33)}{0.23}=\frac{1.8\times 73.33}{0.23}=573.88Pounds$

6 0

3 years ago

A hydraulic jump is induced in an 80 ft wide channel.The water depths on either side of the jump are 1 ft and 10 ft.Please calcu

krek1111 [17]

Answer:

a) 42.08 ft/sec

b) 3366.33 ft³/sec

c) 0.235

d) 18.225 ft

e) 3.80 ft

Explanation:

Given:

b = 80ft

y1 = 1 ft

y2 = 10ft

a) Let's take the formula:

$\frac{y2}{y1} = \frac{1}{5} * \sqrt{1 + 8f^2 - 1}$

$10*2 = \sqrt{1 + 8f^2 - 1$

1 + 8f² = (20+1)²

= 8f² = 440

f² = 55

f = 7.416

For velocity of the faster moving flow, we have :

$\frac{V_1}{\sqrt{g*y_1}} = 7.416$

$V_1 = 7.416 *\sqrt{32.2*1}$

V1 = 42.08 ft/sec

b) the flow rate will be calculated as

Q = VA

VA = V1 * b *y1

= 42.08 * 80 * 1

= 3366.66 ft³/sec

c) The Froude number of the sub-critical flow.

V2.A2 = 3366.66

Where A2 = 80ft * 10ft

Solving for V2, we have:

$V_2 = \frac{3666.66}{80*10}$

= 4.208 ft/sec

Froude number, F2 =

$\frac{V_2}{g*y_2} = \frac{4.208}{32.2*10}$

F2 = 0.235

d) $El = \frac{(y_2 - y_1)^3}{4*y_1*y_2}$

$El = \frac{(10-1)^3}{4*1*10}$

$= \frac{9^3}{40}$

= 18.225ft

e) for critical depth, we use :

$y_c = [\frac{(\frac{3366.66}{80})^2}{32.2}]^1^/^3$

= 3.80 ft

7 0

3 years ago

Read 2 more answers

A well insulated turbine operates at steady state. Steam enters the turbine at 4 MPa with a specific enthalpy of 3015.4 kJ/kg an

Anarel [89]

Answer:

power developed by the turbine = 6927.415 kW

Explanation:

given data

pressure = 4 MPa

specific enthalpy h1 = 3015.4 kJ/kg

velocity v1 = 10 m/s

pressure = 0.07 MPa

specific enthalpy h2 = 2431.7 kJ/kg

velocity v2 = 90 m/s

mass flow rate = 11.95 kg/s

solution

we apply here thermodynamic equation that

energy equation that is

$h1 + \frac{v1}{2} + q = h2 + \frac{v2}{2} + w$

put here value with

turbine is insulated so q = 0

so here

$3015.4 *1000 + \frac{10^2}{2} = 2431.7 * 1000 + \frac{90^2}{2} + w$

solve we get

w = 579700 J/kg = 579.7 kJ/kg

and

W = mass flow rate × w

W = 11.95 × 579.7

W = 6927.415 kW

power developed by the turbine = 6927.415 kW

7 0

3 years ago

8. The operation of a TXV is controlled by the

Katena32 [7]

Answer should be C hopefully

4 0

3 years ago

A world class runner can run long distances at a pace of 15 km/hour. That runner expends 800 kilocalories of energy per hour. a)

maks197457 [2]

Answer: a) 1.05kW b) 3.78MJ c) 5.3 bars

Explanation :

A)

Conversions give 900 kcal as 900000 x 4.2 J/cal {4.2 J/cal is the standard factor}

= 3780kJ

And 1 hour = 3600s

Therefore, Power in watts = 3780/3600 = 1.05kW = 1050W

B)

At 15km/hour a 15km run takes 1 hour.

1 hour is 3600s and the runner burns 1050 joule per second.

Energy used in 1 hour = 3600 x 1050 J/s

= 3780000 J or 3.78MJ

C)

1 mile = 1.61km so 13.1 mile is 13.1 x 1.61 = 21.1km

15km needs 3.78 MJ of energy therefore 21.1km needs 3.78 x 21.1/15 = 5.32MJ =5320 kJ

Finally,

1 Milky Way = 240000 calories = 4.2 x 240000 J = 1008000J or 1008kJ

This means that the runner needs 5320/1008 = 5.3 bars

7 0

3 years ago
